Metal Housing Proximity Sensor Switch High Energy IR Transmitters 0-20M

Sick W12-3 Series Proximity Sensor Switch Photoelectric Proximity Sensor

Applications

The W12-3 family features a complete range of photoelectric sensors that are enclosed in a metal housing. There are a large number of variations that are available, including proximity, retro-reflective, through-beam, special laser and clear material versions. These sensors offer many advantages over conventional optical sensors due to their reliable object detection and monitoring capabilities. Whether in packaging, pharmaceutical, or the food and beverage industries – the W12 family provides a solution for any application.

At a glance

Best-in-class optical performance due to superior OES technology
Autocollimation with retro-reflective sensors
Background and foreground suppression with second emitter LED on proximity sensors
Highly visible, precise light spot and high-energy IR transmitters
Rugged die-cast zinc housing, optional with Teflon® coating
Mounting options with through holes, base blind holes, oblong through holes and dovetail
Flexible sensor settings, monitoring, advanced diagnostics, and visualization thanks to IO-Link

Your Benefits

Reliable detection due to superior ASIC (application-specific integrated circuit) technology and immunity to optical interference factors from the industrial environment
PinPoint LED technology provides a bright, small and precise light spot that enables quick and easy sensor alignment
Precise switching characteristics ensure reliable object detection, reducing downtime caused by re-adjusting sensors during recipe changes
Wide range of products enclosed in a rugged metal housing enables application flexibility in a broad range of industrial environments
Flexible mounting options reduce installation time
IO-Link provides easy data access from the PLC
Quick and easy configuration
Quick and easy integration using function blocks

FEATURES Of WL12-3P2431 For Reference

Sensor/ detection principle	Photoelectric retro-reflective sensor, autocollimation
Dimensions (W x H x D)	15.6 mm x 48.5 mm x 42 mm
Housing design (light emission)	Rectangular
Sensing range max.	0 m ... 7 m 1)
Sensing range	0 m ... 5 m 1)
Type of light	Visible red light
Light source	LED 2)
Light spot size (distance)	Ø 100 mm (3 m)
Angle of dispersion	Approx. 1.5°
Wave length	640 nm
Adjustment	Potentiometer, 5 turns

1) Reflector PL80A.
2) Average service life: 100,000 h at TU = +25 °C.

Models of Sick W12-3 Series Proximity Sensor Switch Photoelectric Proximity Sensor

WTF12-3P2441
WTF12-3P1141
WTF12-3N2441
WTF12-3P2443
WTF12-3P2431
WTF12-3P1131
WTF12-3P2431T01
WTF12-3N2431
WTF12-3N1131
WTF12-3P2433
WTF12-3N2433
WTF12C-3P2433

WTB12-3P2431
WTB12-3P1131
WTB12-3P1111
WTB12-3P2431T01
WTB12-3N1111
WTB12-3N2431
WTB12-3N1131
WTB12-3N1631
WTB12-3P2433
WTB12-3N2433
WTB12-3P2411
WTB12-3P1111
WTB12-3P2411T01
WTB12-3P1711
WTB12-3N2411
WTB12-3N1111
WTB12-3P2413
WTB12-3N2413
WTB12C-3P2413
WTB12C-3P2433
WL12-3P2431
WL12-3P1131
WL12-3P1731
WL12-3P2431T01
WL12-3N2431
WL12-3N1131
WL12-3N2431T01
WL12-3P2441
WL12-3P1141
WL12-3N2441
WL12-3N1141
WL12-3P2451
WL12-3P1151
WL12-3N2451
WL12-3N1151
WL12-3P2461
WL12-3P1161
WL12-3N2461
WL12-3N1161
WL12G-3B2531
WL12G-3O2431
WL12G-3B2531T01
WSE12-3P2431
WSE12-3P1131
WSE12-3P2431T01
WSE12-3N2431
WSE12-3N1131
