Schneider XB4BD Series Push Button Light Switch / Industrial Push Button On Off Switch

Ask Lasest Price
Brand Name :	SCHNEIDER
Model Number :	XB4BD21
Certification :	CE
Price :	consult for best discount
Payment Terms :	T/T, , Western Union,Paypal,, MoneyGram,, L/C
Supply Ability :	1000
Delivery Time :	2-7 days

Add to Cart

Product Details
Company Profile

Schneider XB4BD Series Push Button Light Switch / Industrial Push Button On Off Switch

Schneider XB4BD Series Push Button Electrical Switch Industrial Push-button Press button Switch

Benefits Of Schneider XB4BD Series Push Button Switch

High performance even in the most demanding environments

Attractive design, reinforced with the flush mounting kit

Flexibility and adaptability through modular design

Simplicity and speed of installation

Wide offer providing a solution for all your applications

Datasheet Of Schneider XB4BD Series Push Button Electrical Switch XB4BD21

device short name	XB4
bezel material	Chromium plated metal
fixing collar material	Zamak
mounting diameter	22 mm
sale per indivisible quantity	1
head type	Standard
shape of signaling unit head	Round
type of operator	Stay put
operator profile	Black standard handle
operator position information	2 positions 90°
contacts type and composition	1 NO
contact operation	Slow-break
connections - terminals	Screw clamp terminals : <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1 Screw clamp terminals : >= 1 x 0.22 mm² without cable end conforming to EN/IEC 60947-1

height	47 mm
width	30 mm
depth	68 mm
terminals description ISO n°1	(13-14)NO
product weight	0.095 kg
resistance to high pressure washer	7000000 Pa at 55 °C,distance: 0.1 m
contacts usage	Standard contacts
positive opening	Without positive opening
torque value	0.14 N.m (NO changing electrical state)
mechanical durability	1000000 cycles
tightening torque	0.8...1.2 N.m conforming to EN 60947-1
shape of screw head	Cross head compatible with Philips no 1 screwdriver Cross head compatible with pozidriv No 1 screwdriver Slotted head compatible with flat Ø 4 mm screwdriver Slotted head compatible with flat Ø 5.5 mm screwdriver
contacts material	Silver alloy (Ag/Ni)

After-service:
We Pay high Attention To Your Feed back after receive the goods.
We Provide 18 months warranty after goods arrive.
We Positively Revert Your Complain Within 48hours.
